LM2940CT-5.0
LM2940CT-5.0
Part Number
869
Lion Part
Datasheet
National Semiconductor Manufacture
رگولاتور(لُو دراپ) 5 ولت 1 آمپر با پکیج TO-220-3
Fixed LDO Voltage Regulator 5V 1A TO-220-3
مشخصات LM2940CT-5.0
LM2940CT-5.0
Part Number
1
Number of Outputs
Positive
Polarity
50mV
Line Regulation
Tube
Packaging
Through Hole
Mounting Style
50mV
Load Regulation
0C
Minimum Operating Temperature
Fixed
Output Type
+125C
Maximum Operating Temperature
72dB
PSRR - Ripple Rejection - Typ
26V
Input Voltage Max
500mV
Dropout Voltage
15mA
Quiescent Current
6.25V
Input Voltage Min
1A
Output Current
5V
Output Voltage
TO-220-3
Package-Case
