فیوز ریستشونده 30 ولت جریان نگهدارنده 200 میلیآمپر سایز 1210
PTC Resettable Fuse 30V, 200mA with 1210 Size
Specifications
- Maximum Voltage: 30VDC
- Hold Current: 200mA
- Trip Current: 400mA
- Current Rating - Max: 10A
- Resistance: 5Ω
- Package/Case: 1210 (3225 metric)
- Minimum Operating Temperature: -40C
- Maximum Operating Temperature: +85C
- Packaging: Reel
مشخصات MF-USMF020-2
MF-USMF020-2
Part Number
10A
Current Rating - Max
400mA
Trip Current
200mA
Hold Current
SMD/SMT
Termination style
Reel
Packaging
-40C
Minimum Operating Temperature
SMD/SMT
Mounting Style
30VDC
Maximum Voltage
+85C
Maximum Operating Temperature
600mW
Pd - Power Dissipation
1210 (3225 metric)
Package-Case
Resetteble Fuses - PPTC
Product Type
5Ω
Resistance
