MBR10200FCT
MBR10200FCT
Part Number
2409
Lion Part
Datasheet
PANJIT International Manufacture
دیود شاتکی 200 ولت 10 آمپر با پکیج TO-220-3
Schottky Diode 200V, 10A with TO-220-3 Package
معرفی
دیود شاتکی 200 ولت 10 آمپر با پکیج TO-220-3
Schottky Diode 200V, 10A with TO-220-3 Package
Specifications
- Configuration: Dual Common Cathode
- Vrrm - Repetitive Reverse Voltage: 200V
- If - Forward Current: 10A
- Ifsm - Forward Surge Current: 150A
- Vf - Forward Voltage: 810mV
- Ir - Reverse Current: 50uA
- Mounting Style: Through Hole
- Package/Case: TO-220-3
- Minimum Operating Temperature: -65C
- Maximum Operating Temperature: +175C
- Packaging: Tube
مشخصات دیود شاتکی MBR10200FCT
دیود شاتکی MBR10200FCT
Part Number
-65C
Minimum Operating Temperature
Tube
Packaging
Through Hole
Mounting Style
200V
Vrrm - Repetitive Reverse Voltage
50uA
Ir - Reverse Current
150A
Ifsm - Forward Surge Current
+175C
Maximum Operating Temperature
810mV
Vf - Forward Voltage
Dual Common Cathode
Configuration
10A
If - Forward Current
TO-220
Package-Case
