BSZ034N04LS
BSZ034N04LS
Part Number
3328
Lion Part
Datasheet
Infineon Technologies Manufacture
ماسفت 40 ولت 90 آمپر نوع N با پکیج TSDSON-8
N-CH MOSFET 40V, 90A with TSDSON-8 Package
معرفی
ماسفت 40 ولت 90 آمپر نوع N با پکیج TSDSON-8
N-CH MOSFET 40V, 90A with TSDSON-8 Package
Specifications
- Package/Case: TSDSON-8
- Vds - Drain - Source Breakdown Voltage: 40V
- Id - Continuous Drain Current: 95A
- Transistor Polarity: N-Channel
- Channel Mode: Enhancement
- Number of Channels: 1
- Vgs th - Gate - Source Threshold Voltage: 1.2V
- Vgs - Gate - Source Voltage: ±20V
- Rds On - Drain - Source Resistance: 2.7mΩ
- Pd - Power Dissipation: 52W
- Qg - Gate Charge: 25nC
- Mounting Style: SMD/SMT
- Minimum Operating Temperature: -55C
- Maximum Operating Temperature: +150C
- Packaging: Reel
مشخصات ماسفت BSZ034N04LS
ماسفت BSZ034N04LS
Part Number
1
Number of Channels
Enhancement
Channel Mode
-55C
Minimum Operating Temperature
Reel
Packaging
SMD/SMT
Mounting Style
±20V
Vgs - Gate - Source Voltage
40V
Vds - Drain - Source Breakdown Voltage
+150C
Maximum Operating Temperature
2.7mΩ
Rds On - Drain - Source Resistance
1.2V
Vgs th - Gate - Source Threshold Voltage
25nC
Qg - Gate Charge
52W
Pd - Power Dissipation
95A
Id - Continuous Drain Current
TSDSON-8
Package-Case
