UP9646AQDBA

Part Number

UP9646AQDBA

Datasheet

Lion Part

5576

Manufacturer

uPI Semiconductor

Description

درایور قدرت 30 ولت مجتمع برای مبدل DC-DC سنکرون چندفاز

UP9646 is a driver integrated 30V power stage module for multi-phase synchronous buck DC-DC converter

موجودی محصول

در صورت کمبود موجودی محصول می توانید آنرا به لیست استعلام اضافه نمایید تا توسط کارشناسان واحد سفارشات خارجی بررسی شده و نتیجه به شما اطلاع داده شود

قیمت محصول

تعداد	قیمت
1	1,342,677 ریال
10	1,253,165 ریال
100	1,208,409 ریال

معرفی

he UP9646 is a driver integrated 30V power stage module for multi-phase synchronous buck DC-DC converter in desktop and notebook applications. The device is operated with 5V input for integrated MOSFET driver, and its MOSFETs are fully optimized to deliver up to 50A output current with high conversion efficiency for CPU, GPU and DDR memory power supplies. This part features Intel® PS4 mode support, thermal warning, over current protection, and zero current detection functions. The thermal warning output is used by system to secure safety operation. The over current protection function of the device further enhances protection for the converter. The zero current detection function provides more application flexibility. The uP9646 also provides comprehensive protection functions, including under voltage lockout for VCC/VDRV, and over temperature protection. The uP9646 is available with a compact WQFN 5×5-31L package.

مشخصات UP9646AQDBA

Part Number

UP9646AQDBA
Number of Drivers

1
Number of Outputs

1
Number of Channels

2
Channel Mode

Enhancement
Transistor Polarity

N-Channel
Packaging

Reel
Vgs - Gate - Source Voltage

±5V
Minimum Operating Temperature

-40C
Mounting Style

SMD/SMT
Maximum Operating Temperature

+85C
Vds - Drain - Source Breakdown Voltage

30V
Supply Voltage - Min

2.5V
Supply Voltage - Max

25V
Vgs th - Gate - Source Threshold Voltage

N/A
Switching Frequency

2MHz
Output Current

50A
Id - Continuous Drain Current

50A
Qg - Gate Charge

N/A
Rds On - Drain - Source Resistance

N/A
Pd - Power Dissipation

5.68W
Package-Case

WQFN5x5-31L

موجودی محصول	50
