MCP3550-50E/SN
MCP3550-50E/SN
Part Number
679
Lion Part
Datasheet
Microchip Technology Manufacture
مبدل آنالوگ به دیجیتال 22 بیت 1 کاناله با نرخ نمونهبرداری 12S/s و رابط 3-Wire, SPI، معماری Delta-Sigma، کالیبراسیون داخلی Offset/Gain، کممصرف با پکیج SOIC-8
ADC 22bit, 1 Channel with 12S/s and 3-Wire, SPI Interface, Delta-Sigma ADCs, Internal Offset/Gain Calibration, Low Power with SOIC-8 Package
معرفی
مبدل آنالوگ به دیجیتال 22 بیت 1 کاناله با نرخ نمونهبرداری 12S/s و رابط 3-Wire, SPI، معماری Delta-Sigma، کالیبراسیون داخلی Offset/Gain، کممصرف با پکیج SOIC-8
ADC 22bit, 1 Channel with 12S/s and 3-Wire, SPI Interface, Delta-Sigma ADCs, Internal Offset/Gain Calibration, Low Power with SOIC-8 Package
Specifications
- Number of Channels: 1
- Interface Type: 3-Wire, SPI
- Resolution: 22bit
- Sampling Rate: 12S/s
- Analog Supply Voltage: 2.7 - 5.5V
- Digital Supply Voltage: 2.7V to 5.5V
- Input Type: Differential
- Architecture: Sigma-Delta
- Mounting Style: SMD/SMT
- Package/Case: SOIC-8
- Minimum Operating Temperature: -40C
- Maximum Operating Temperature: +125C
- Packaging: Tube
مشخصات MCP3550-50E/SN
MCP3550-50E/SN
Part Number
1
Number of Channels
12S/s
Sampling Rate
Differential
Input Type
-40C
Minimum Operating Temperature
Sigma-Delta
Architecture
Tube
Packaging
SMD/SMT
Mounting Style
2.7 - 5.5V
Analog Supply Voltage
22bit
Resolution
+125C
Maximum Operating Temperature
3-Wire, SPI
Interface Type
2.7V to 5.5V
Digital Supply Voltage
N/A
SNR - Signal to Noise Ratio
SOIC-8
Package-Case
