2SD882
2SD882
Part Number
140
Lion Part
Datasheet
STMicroelectronics Manufacture
ترانزیستور NPN با ولتاژ 30 ولت و جریان 3 آمپر با پکیج SOT-32-3
BJT NPN 30V, 3A with SOT-32-3 Package
معرفی
ترانزیستور NPN با ولتاژ 30 ولت و جریان 3 آمپر با پکیج SOT-32-3
BJT NPN 30V, 3A with SOT-32-3 Package
Specifications
- Transistor Polarity: NPN
- Configuration: Single
- Collector - Emitter Voltage VCEO Max: 30V
- Maximum DC Collector Current: 3A
- Gain Bandwidth Product fT: 100MHz
- Pd - Power Dissipation: 12.5W
- Mounting Style: Through Hole
- Package/Case: SOT-32-3
- Minimum Operating Temperature: -65C
- Maximum Operating Temperature: +150C
- Packaging: Tube
مشخصات 2SD882
2SD882
Part Number
-65C
Minimum Operating Temperature
100MHz
Gain Bandwidth Product fT
Tube
Packaging
Through Hole
Mounting Style
30V
Collector - Emitter Voltage VCEO Max
+150C
Maximum Operating Temperature
3A
Maximum DC Collector Current
Single
Configuration
12.5W
Pd - Power Dissipation
TO-126
Package-Case
