DLW31SN900SQ2L
DLW31SN900SQ2L
Part Number
1500
Lion Part
Datasheet
Murata Manufacturing Manufacture
چوکفیلتر مد مشترک 1 کاناله، امپدانس 90 اهم، 50 ولت، مقاومت DC برابر 300 میلیاهم با پکیج 1206
Common Mode Chokes / Filters 1 Channel, 90Ω Impedance, 50V, 300mΩ DC Resistance with 1206 Package
معرفی
چوکفیلتر مد مشترک 1 کاناله، امپدانس 90 اهم، 50 ولت، مقاومت DC برابر 300 میلیاهم با پکیج 1206
Common Mode Chokes / Filters 1 Channel, 90Ω Impedance, 50V, 300mΩ DC Resistance with 1206 Package
Specifications
- Product: Common Mode Chokes
- Number of Channels: 1
- Inductance: 143nH
- Impedance: 90Ω
- Maximum DC Current: 370mA
- Maximum DC Resistance: 300mΩ
- Termination style: SMD/SMT
- Mounting Style: PCB Mount
- Package/Case: 1206 (3216 metric)
- Minimum Operating Temperature: -40C
- Maximum Operating Temperature: +125C
- Packaging: Reel
مشخصات DLW31SN900SQ2L
DLW31SN900SQ2L
Part Number
1
Number of Channels
Unshielded
Shielding
SMD/SMT
Termination style
90Ω
Impedance
Reel
Packaging
-40C
Minimum Operating Temperature
143nH
Inductance
PCB Mount
Mounting Style
Common Mode Chokes / Filters
Product Type
+125C
Maximum Operating Temperature
Common Mode Chokes
Product
370mA
Maximum DC Current
1206 (3216 metric)
Package-Case
300mΩ
Maximum DC Resistance
