DTA143EKAT
DTA143EKAT
Part Number
163
Lion Part
Datasheet
ROHM Semiconductor Manufacture
ترانزیستور 50 ولت 100 میلی آمپر PNP با پکیج SC-59-3
BJT PNP 50V 100mA SC-59-3
TAPE محصول ایراد دارد و مناسب مونتاژ ماشینی نیست
مشخصات DTA143EKAT
DTA143EKAT
Part Number
100mA
Peak DC Collector Current
-100mA
Continuous Collector Current
1
Typical Resistor Ratio
-55C
Minimum Operating Temperature
Reel
Packaging
-50V
Collector - Emitter Voltage VCEO Max
SMD/SMT
Mounting Style
PNP
Transistor Polarity
-100mA
Maximum DC Collector Current
200mW
Pd - Power Dissipation
250MHz
Gain Bandwidth Product fT
+200C
Maximum Operating Temperature
Single
Configuration
SC-59-3
Package-Case
