DLW31SN102SQ2L
DLW31SN102SQ2L
Part Number
2841
Lion Part
Datasheet
Murata Manufacturing Manufacture
چوکفیلتر مد مشترک 1 کاناله، امپدانس 1000 اهم 50 ولت، مقاومت DC برابر 1 اهم با پکیج 1206
Common Mode Chokes / Filters 1 Channel, 1000Ω 50V, 1Ω DC Resistance with 1206 Package
معرفی
چوکفیلتر مد مشترک 1 کاناله، امپدانس 1000 اهم 50 ولت، مقاومت DC برابر 1 اهم با پکیج 1206
Common Mode Chokes / Filters 1 Channel, 1000Ω 50V, 1Ω DC Resistance with 1206 Package
Specifications
- Product: Common Mode Chokes
- Number of Channels: 1
- Self Resonant Frequency: 120MHz
- Inductance: 1.5uH
- Impedance: 1kΩ
- Maximum DC Current: 230mA
- Maximum DC Resistance: 1Ω
- Termination style: SMD/SMT
- Mounting Style: PCB Mount
- Package/Case: 1206 (3216 metric)
- Minimum Operating Temperature: -40C
- Maximum Operating Temperature: +85C
- Packaging: Reel
مشخصات فیلتر دوبل DLW31SN102SQ2L
فیلتر دوبل DLW31SN102SQ2L
Part Number
1
Number of Channels
Reel
Packaging
SMD/SMT
Termination style
-40C
Minimum Operating Temperature
120MHz
Self Resonant Frequency
PCB Mount
Mounting Style
+85C
Maximum Operating Temperature
1kΩ
Impedance
1.5uH
Inductance
230mA
Maximum DC Current
Common Mode Chokes
Product
1206 (3216 metric)
Package-Case
1Ω
Maximum DC Resistance
