FEP30GP
FEP30GP
Part Number
65
Lion Part
Datasheet
Vishay Semiconductors Manufacture
دیود فست 400 ولت 30 آمپر زمان بازیابی 50 نانوثانیه با پکیج TO-247AD
Fast Diode 30A, 400V with 50ns Recovery Time and TO-247AD Package
معرفی
دیود فست 400 ولت 30 آمپر زمان بازیابی 50 نانوثانیه با پکیج TO-247AD
Fast Diode 30A, 400V with 50ns Recovery Time and TO-247AD Package
Specifications
- Configuration: Dual Common Cathode
- Recovery Time: 50ns
- Vr - Reverse Voltage: 400V
- If - Forward Current: 30A
- Max Surge Current: 300A
- Vf - Forward Voltage: 1.3V
- Ir - Reverse Current: 10uA
- Mounting Style: Through Hole
- Package/Case: TO-247AD
- Minimum Operating Temperature: -55C
- Maximum Operating Temperature: +150C
- Packaging: Tube
مشخصات FEP30GP
FEP30GP
Part Number
-55C
Minimum Operating Temperature
Tube
Packaging
10uA
Ir - Reverse Current
50ns
Recovery Time
Through Hole
Mounting Style
400V
Vr - Reverse Voltage
Dual Common Cathode
Configuration
+150C
Maximum Operating Temperature
300A
Max Surge Current
1.3V
Vf - Forward Voltage
30A
If - Forward Current
TO-247
Package-Case
