HT1E107M0605PC
HT1E107M0605PC
Part Number
5316
Lion Part
Datasheet
Honor Elec Manufacture
خازن جامد پلیمری 100 میکروفاراد 25 ولت تلرانس 20% سایز 6.3 میلیمتر در 5.5 میلیمتر
Solid Polymer Electrolytic Capacitor 100uF 25V 20% 6.3mmx5.5mm
معرفی
خازن جامد پلیمری 100 میکروفاراد 25 ولت تلرانس 20% سایز 6.3 میلیمتر در 5.5 میلیمتر
Solid Polymer Electrolytic Capacitor 100uF 25V 20% 6.3mmx5.5mm
Specifications
- Life: 2000 Hour
- Capacitance: 100uF
- Voltage Rating DC: 25VDC
- ESR: 55mΩ
- Ripple Current: 850mA
- Tolerance: 20%
- Lead Spacing: 2.5mm
- Diameter: 6.3mm
- Height: 5.5mm
- Mounting Style: Through Hole
- Minimum Operating Temperature: -55C
- Maximum Operating Temperature: +125C
- Packaging: Bulk
مشخصات HT1E107M0605PC
HT1E107M0605PC
Part Number
2.5mm
Lead Spacing
2000 Hour
Life
-55C
Minimum Operating Temperature
Bulk
Packaging
25VDC
Voltage Rating DC
Through Hole
Mounting Style
6.3mm
Diameter
20%
Tolerance
55mΩ
ESR
+125C
Maximum Operating Temperature
850mA
Ripple Current
5.5mm
Height
100uF
Capacitance
