HG1V108M1016PC
HG1V108M1016PC
Part Number
7028
Lion Part
Datasheet
Honor Elec Manufacture
خازن الکترولیت جامد پلیمری 1000 میکروفاراد 35 ولت تلرانس 20% سایز 10 میلیمتر در 16 میلیمتر
Solid Polymer Electrolytic Capacitor 1000uF 35V 20% Tolerance 10mmx16mm
معرفی
خازن الکترولیت جامد پلیمری 1000 میکروفاراد 35 ولت تلرانس 20% سایز 10 میلیمتر در 16 میلیمتر
Solid Polymer Electrolytic Capacitor 1000uF 35V 20% Tolerance 10mmx16mm
Specifications
- Life: 2000 Hour
- Capacitance: 1000uF
- Voltage Rating DC: 35VDC
- ESR: 28mΩ
- Ripple Current: 4.2A
- Tolerance: -20%, +20%
- Lead Spacing: 5mm
- Diameter: 10mm
- Height: 16mm
- Mounting Style: Through Hole
- Minimum Operating Temperature: -55C
- Maximum Operating Temperature: +105C
- Packaging: Bag
مشخصات HG1V108M1016PC
HG1V108M1016PC
Part Number
2000 Hour
Life
Bag
Packaging
-20%, +20%
Tolerance
-55C
Minimum Operating Temperature
5mm
Lead Spacing
28mΩ
ESR
Through Hole
Mounting Style
35VDC
Voltage Rating DC
+105C
Maximum Operating Temperature
10mm
Diameter
4.2A
Ripple Current
16mm
Height
1000uF
Capacitance
