Lelon
معرفی
خازن الکترولیت 680 میکروفاراد 16 ولت تلرانس 20% سایز 10 میلیمترx10 میلیمتر
Aluminum Electrolytic Capacitor 680uF, 16V, 20% with 10mmx10mm Size
Specifications
- Life: 5000 Hour
- Capacitance: 680uF
- Voltage Rating DC: 16VDC
- Ripple Current: 670mA
- ESR: 90mΩ
- Tolerance: 20%
- Diameter: 10mm
- Height: 10mm
- Minimum Operating Temperature: -55C
- Maximum Operating Temperature: +105C
- Packaging: Reel
مشخصات VZH681M1CTR-1010
VZH681M1CTR-1010
Part Number
-55C
Minimum Operating Temperature
Reel
Packaging
5000 Hour
Life
16VDC
Voltage Rating DC
+105C
Maximum Operating Temperature
20%
Tolerance
10mm
Diameter
90mΩ
ESR
670mA
Ripple Current
10mm
Height
680uF
Capacitance
