HG1H107M0808PC
HG1H107M0808PC
Part Number
5307
Lion Part
Datasheet
Honor Elec Manufacture
خازن الکترولیت جامد پلیمری 100 میکروفاراد 50 ولت تلرانس 20% سایز 8 میلیمتر در 8 میلیمتر
Solid Polymer Aluminum Electrolytic Capacitor 100uF 50V 20% 8mmx8mm
معرفی
خازن الکترولیت جامد پلیمری 100 میکروفاراد 50 ولت تلرانس 20% سایز 8 میلیمتر در 8 میلیمتر
Solid Polymer Aluminum Electrolytic Capacitor 100uF 50V 20% 8mmx8mm
Specifications
- Life: 2000 Hour
- Capacitance: 100uF
- Voltage Rating DC: 50VDC
- ESR: 42mΩ
- Ripple Current: 2.3A
- Tolerance: 20%
- Lead Spacing: 3.5mm
- Diameter: 8mm
- Height: 8mm
- Mounting Style: Through Hole
- Minimum Operating Temperature: -55C
- Maximum Operating Temperature: +105C
- Packaging: Bulk
مشخصات HG1H107M0808PC
HG1H107M0808PC
Part Number
2000 Hour
Life
3.5mm
Lead Spacing
-55C
Minimum Operating Temperature
Bulk
Packaging
Through Hole
Mounting Style
42mΩ
ESR
8mm
Diameter
20%
Tolerance
+105C
Maximum Operating Temperature
50VDC
Voltage Rating DC
2.3A
Ripple Current
8mm
Height
100uF
Capacitance
