4N33M
4N33M
Part Number
543
Lion Part
Datasheet
FAIRCHILD/ONSEMI Manufacture
اپتوکوپلر- فتوکوپلر 1.5 ولت 80 میلیآمپر 250 میلیوات با پکیج PDIP-6
6Pin DIP General Purpose Photodarlington Optocoupler
مشخصات 4N33M
4N33M
Part Number
1
Number of Channels
108%
Maximum CTR
DC
Input Type
-40C
Minimum Operating Temperature
Tube
Packaging
Through Hole
Mounting Style
+100C
Maximum Operating Temperature
30V
Collector - Emitter Voltage VCEO Max
80mA
If - Forward Current
7.5kVrms
Isolation Voltage
250mW
Pd - Power Dissipation
Photodarlington
Output Type
1.5V
Vf - Forward Voltage
DIP-6
Package-Case
Transistor Output Optocouplers
Product Type
