TDK
معرفی
وریستور 250 ولت AC ولتاژ وریستور 390 ولت جریان ضربه 8 کیلوآمپر سایز 20 میلیمتر تلرانس 10% استاندارد
Varistor 250 VAC, Varistor Voltage 390V with 8kA Peak Surge Current, 20mm Size, 10% Standard
Specifications
- Product: MOV
- Varistor Voltage: 390V
- Clamping Voltage: 650V
- Voltage Rating AC: 250 VAC
- Voltage Rating DC: 320VDC
- Peak Surge Current: 8kA
- Surge Energy Rating: 140J
- Capacitance: 940pF
- Diameter: 20mm
- Mounting Style: Through Hole
- Minimum Operating Temperature: -40C
- Maximum Operating Temperature: +105C
- Packaging: Bulk
مشخصات وریستور B72220S0251K101
وریستور B72220S0251K101
Part Number
390V
Varistor Voltage
250 VAC
Voltage Rating AC
Bulk
Packaging
-40C
Minimum Operating Temperature
8kA
Peak Surge Current
Through Hole
Mounting Style
+105C
Maximum Operating Temperature
140J
Surge Energy Rating
320VDC
Voltage Rating DC
20mm
Diameter
940pF
Capacitance
650V
Clamping Voltage
MOV
Product
N/A
Package-Case
