L78L12ACUTR
L78L12ACUTR
Part Number
6237
Lion Part
Datasheet
STMicroelectronics Manufacture
رگولاتور خطی 12 ولت 100 میلیآمپر با پکیج SOT-89
Linear Voltage Regulator 12V, 100mA with SOT-89 Package
معرفی
رگولاتور خطی 12 ولت 100 میلیآمپر با پکیج SOT-89
Linear Voltage Regulator 12V, 100mA with SOT-89 Package
Specifications
- Polarity: Positive
- Output Type: Fixed
- Number of Outputs: 1
- Output Voltage: 12V
- Output Current: 100mA
- Input Voltage Min: 14V
- Input Voltage Max: 35V
- Load Regulation: 100mV
- Line Regulation: 250mV
- Quiescent Current: 6.5mA
- Mounting Style: SMD/SMT
- Package/Case: SOT-89
- Minimum Operating Temperature: 0C
- Maximum Operating Temperature: +125C
- Packaging: Reel
مشخصات L78L12ACUTR
L78L12ACUTR
Part Number
1
Number of Outputs
Reel
Packaging
Positive
Polarity
SMD/SMT
Mounting Style
0C
Minimum Operating Temperature
100mV
Load Regulation
Fixed
Output Type
+125C
Maximum Operating Temperature
250mV
Line Regulation
100mA
Output Current
35V
Input Voltage Max
6.5mA
Quiescent Current
14V
Input Voltage Min
12V
Output Voltage
SOT-89
Package-Case
