TDK
معرفی
وریستور 275 ولت AC ولتاژ وریستور 430 ولت جریان ضربه 1.2 کیلوآمپر سایز 7 میلیمتر
Varistor 275VAC 10%, Varistor Voltage 430V with 1.2kA Peak Surge Current, 7mm Standard
Specifications
- Product: MOV
- Varistor Voltage: 430V
- Clamping Voltage: 710V
- Voltage Rating AC: 275VAC
- Voltage Rating DC: 350VDC
- Peak Surge Current: 1.2kA
- Surge Energy Rating: 21J
- Capacitance: 110pF
- Diameter: 7mm
- Mounting Style: Through Hole
- Minimum Operating Temperature: -40C
- Maximum Operating Temperature: +105C
- Packaging: Bulk
مشخصات وریستور B72207S0271K101
وریستور B72207S0271K101
Part Number
430V
Varistor Voltage
1.2kA
Peak Surge Current
Bulk
Packaging
275VAC
Voltage Rating AC
21J
Surge Energy Rating
-40C
Minimum Operating Temperature
Through Hole
Mounting Style
7mm
Diameter
+105C
Maximum Operating Temperature
110pF
Capacitance
350VDC
Voltage Rating DC
710V
Clamping Voltage
MOV
Product
N/A
Package-Case
