معرفی
ال ای دی آبی 455-475nm با جریان 25 میلیآمپر و توان 75 میلیوات با پکیج 0805
LED Blue 455-475nm, 25mA, 75mW with 0805 Package
Specifications
- Illumination Color: Blue
- Vf - Forward Voltage: 2.6-3.1V
- If - Forward Current: 25mA
- Power Rating: 75mW
- Wavelength/Color Temperature: 455-475nm
- Luminous Intensity: 42-86mcd
- Package/Case: 0805 (2012 metric)
- Mounting Style: SMD/SMT
- Minimum Operating Temperature: -30C
- Maximum Operating Temperature: +85C
- Packaging: Reel
مشخصات ال ای دی آبی XL-2012UBC
ال ای دی آبی XL-2012UBC
Part Number
Blue
Illumination Color
Reel
Packaging
75mW
Power Rating
-30C
Minimum Operating Temperature
SMD/SMT
Mounting Style
42-86mcd
Luminous Intensity
+85C
Maximum Operating Temperature
25mA
If - Forward Current
455-475nm
Wavelength-Color Temperature
0805 (2012 metric)
Package-Case
2.6-3.1V
Vf - Forward Voltage
