IRM-05-5
MEAN WELL
معرفی
منبع تغذیه 5 وات خروجی 5 ولت 1 آمپر ورودی 85 تا 305 ولت AC، ماژول مبدل AC به DC سوئیچینگ ایزوله سبز (کممصرف) مخصوص مونتاژ روی PCB
Power Supply 5W, 5V 1A with 85 - 305VAC Input, 5W AC-DC PCB-Mount Green Power Module
Specifications
- Input Voltage: 85 - 305VAC
- Number of Outputs: 1
- Output Voltage - Channel 1: 5V
- Output Current - Channel 1: 1A
- Output Power: 5W
- Open Frame/Enclosed: Enclosed
- Length: 45.7mm
- Width: 25.4mm
- Height: 21.5mm
- Mounting Style: Through Hole
- Product: AC/DC Power Modules
مشخصات مبدل AC/DC ایزوله IRM-05-5
مبدل AC/DC ایزوله IRM-05-5
Part Number
1
Number of Outputs
Enclosed
Open Frame-Enclosed
AC/DC Power Modules
Product
5V
Output Voltage - Channel 1
N/A
Output Voltage - Channel 2
Through Hole
Mounting Style
N/A
Output Current - Channel 2
5W
Output Power
1A
Output Current - Channel 1
25.4mm
Width
85 - 305VAC
Input Voltage
45.7mm
Length
21.5mm
Height
