LM78L05ACMX
LM78L05ACMX
Part Number
880
Lion Part
Datasheet
National Semiconductor Manufacture
رگولاتور خطی ثابت 5 ولت 100 میلیآمپر با پکیج SOIC-8
Fixed Linear Voltage Regulator 5V, 100mA with SOIC-8 Package
معرفی
رگولاتور خطی ثابت 5 ولت 100 میلیآمپر با پکیج SOIC-8
Fixed Linear Voltage Regulator 5V, 100mA with SOIC-8 Package
Specifications
- Polarity: Positive
- Output Type: Fixed
- Number of Outputs: 1
- Output Voltage: 5V
- Output Current: 100mA
- Input Voltage Min: 6.7V
- Input Voltage Max: 35V
- Load Regulation: 60mV
- Line Regulation: 75mV
- Quiescent Current: 5mA
- Mounting Style: SMD/SMT
- Package/Case: SOIC-8
- Minimum Operating Temperature: -40C
- Maximum Operating Temperature: +125C
- Packaging: Reel
مشخصات LM78L05ACMX
LM78L05ACMX
Part Number
Reel
Packaging
Positive
Polarity
-40C
Minimum Operating Temperature
SMD/SMT
Mounting Style
75mV
Line Regulation
60mV
Load Regulation
Fixed
Output Type
+125C
Maximum Operating Temperature
100mA
Output Current
35V
Input Voltage Max
5mA
Quiescent Current
6.7V
Input Voltage Min
5V
Output Voltage
SOIC-8
Package-Case
