TLV75901PDRVR
TLV75901PDRVR
Part Number
4875
Lion Part
Datasheet
Texas Instruments Manufacture
رگولاتور LDO با خروجی قابل تنظیم 0.55 تا 5.5 ولت 1 آمپر با دقت بالا با پکیج WSON-6
High Accuracy Adjustable LDO Voltage Regulator 0.55 - 5.5V, 1A with WSON-6 Package
معرفی
رگولاتور LDO با خروجی قابل تنظیم 0.55 تا 5.5 ولت 1 آمپر با دقت بالا با پکیج WSON-6
High Accuracy Adjustable LDO Voltage Regulator 0.55 - 5.5V, 1A with WSON-6 Package
Specifications
- Polarity: Positive
- Output Type: Adjustable
- Package/Case: WSON-6
- Output Voltage: 0.55 - 5.5V
- Output Current: 1A
- Dropout Voltage: 200mV
- Input Voltage Min: 1.5V
- Input Voltage Max: 6V
- PSRR / Ripple Rejection - Typ: 50dB
- Quiescent Current: 25uA
- Mounting Style: SMD/SMT
- Number of Outputs: 1
- Minimum Operating Temperature: -40C
- Maximum Operating Temperature: +125C
- Packaging: Reel
مشخصات رگولاتور(LDO) TLV75901PDRVR
رگولاتور(LDO) TLV75901PDRVR
Part Number
1
Number of Outputs
Reel
Packaging
50dB
PSRR - Ripple Rejection - Typ
-40C
Minimum Operating Temperature
Positive
Polarity
SMD/SMT
Mounting Style
6V
Input Voltage Max
Adjustable
Output Type
200mV
Dropout Voltage
+125C
Maximum Operating Temperature
25uA
Quiescent Current
1.5V
Input Voltage Min
0.55 - 5.5V
Output Voltage
1A
Output Current
WSON-6
Package-Case
