دیود تی وی اس SMAJ15A
SMAJ15A
Part Number
3593
Lion Part
Datasheet
Littelfuse Manufacture
دیود TVS یک جهته 15 ولت با بیشنه پالس جریان 16.4 آمپر با پکیج SMA
TVS Diode Uni-directional 15V SMA
مشخصات دیود تی وی اس SMAJ15A
دیود تی وی اس SMAJ15A
Part Number
1
Number of Channels
-65C
Minimum Operating Temperature
30kV
Vesd - Voltage ESD Air Gap
SMD/SMT
Termination style
30kV
Vesd - Voltage ESD Contact
Reel
Packaging
Unidirectional
Polarity
400W
Pppm - Peak Pulse Power Dissipation
+150C
Maximum Operating Temperature
15V
Working Voltage
24.4V
Clamping Voltage
N/A
Cd - Diode Capacitance
16.7V
Breakdown Voltage
16.4A
Ipp - Peak Pulse Current
TVS Diodes
Product Type
DO-214AC (SMA)
Package-Case
