FOSAN
معرفی
دیود TVS یکجهته 26 ولت با جریان پالس 4.75 آمپر با پکیج SOD-123FL
TVS Diode 26V Unidirectional, 4.75A Peak Pulse Current with SOD-123FL Package
Specifications
- Product Type: TVS Diodes
- Polarity: Unidirectional
- Number of Channels: 1
- Working Voltage: 26V
- Breakdown Voltage: 28.9V
- Clamping Voltage: 42.1V
- Vesd - Voltage ESD Contact: 30kV
- Vesd - Voltage ESD Air Gap: 30kV
- Ipp - Peak Pulse Current: 4.75A
- Termination style: SMD/SMT
- Package/Case: SOD-123FL
- Minimum Operating Temperature: -55C
- Maximum Operating Temperature: +150C
- Packaging: Reel
مشخصات SMF26A
SMF26A
Part Number
1
Number of Channels
-55C
Minimum Operating Temperature
30kV
Vesd - Voltage ESD Air Gap
30kV
Vesd - Voltage ESD Contact
SMD/SMT
Termination style
Reel
Packaging
Unidirectional
Polarity
+150C
Maximum Operating Temperature
N/A
Pppm - Peak Pulse Power Dissipation
26V
Working Voltage
N/A
Cd - Diode Capacitance
42.1V
Clamping Voltage
28.9V
Breakdown Voltage
4.75A
Ipp - Peak Pulse Current
TVS Diodes
Product Type
SOD-123F
Package-Case
