SMF30A
SMF30A
Part Number
3771
Lion Part
Datasheet
Littelfuse Manufacture
دیود TVS یک جهته 30 ولت با بیشنه پالس جریان 4.1 آمپر با پکیج SOD-123-2
TVS Diode Uni-directional 30V SOD-123-2
معرفی
دیود TVS یک جهته 30 ولت با بیشنه پالس جریان 4.1 آمپر با پکیج SOD-123-2
TVS Diode Uni-directional 30V SOD-123-2
Specifications
- Product Type: TVS Diodes
- Polarity: Unidirectional
- Number of Channels: 1
- Working Voltage: 30V
- Breakdown Voltage: 33.3V
- Clamping Voltage: 48.4V
- Pppm - Peak Pulse Power Dissipation: 200W
- Vesd - Voltage ESD Contact: 30kV
- Vesd - Voltage ESD Air Gap: 30kV
- Ipp - Peak Pulse Current: 4.1A
- Termination style: SMD/SMT
- Package/Case: SOD-123-2
- Minimum Operating Temperature: -65C
- Maximum Operating Temperature: +150C
- Packaging: Reel
مشخصات دیود تیویاس SMF30A
دیود تیویاس SMF30A
Part Number
1
Number of Channels
-65C
Minimum Operating Temperature
30kV
Vesd - Voltage ESD Air Gap
SMD/SMT
Termination style
Reel
Packaging
30kV
Vesd - Voltage ESD Contact
Unidirectional
Polarity
200W
Pppm - Peak Pulse Power Dissipation
4.1A
Ipp - Peak Pulse Current
+150C
Maximum Operating Temperature
30V
Working Voltage
N/A
Cd - Diode Capacitance
48.4V
Clamping Voltage
33.3V
Breakdown Voltage
TVS Diodes
Product Type
SOD-123-2
Package-Case
