CC6201ST
CC6201ST
Part Number
6005
Lion Part
Datasheet
Cross chip Manufacture
سوئیچ اثر هال همهقطبیده با ولتاژ 2 تا 5 ولت و نقطه عملکرد ±40G با پکیج SOT-23-3
Temperature-Stable, Micropower, Ultra Sensitive, Omnipolar Hall Effect Switch, 2 - 5V, Operating Point ±40G with SOT-23-3 Package
معرفی
سوئیچ اثر هال همهقطبیده با ولتاژ 2 تا 5 ولت و نقطه عملکرد ±40G با پکیج SOT-23-3
Temperature-Stable, Micropower, Ultra Sensitive, Omnipolar Hall Effect Switch, 2 - 5V, Operating Point ±40G with SOT-23-3 Package
Specifications
- Type: Hall-Effect Switch
- Operating Point Min/Max: ±40G
- Release Point Min/Max (Brp): ±32G
- Operating Supply Voltage: 2 - 5V
- Operating Supply Current: 2mA
- Mounting Style: SMD/SMT
- Package/Case: SOT-23-3
- Minimum Operating Temperature: -40C
- Maximum Operating Temperature: +150C
- Packaging: Reel
مشخصات هال سوئیچ CC6201ST
هال سوئیچ CC6201ST
Part Number
--- 2 - 5V
Operating Supply Voltage
--- SOT-23-3
Package-Case
--- Hall-Effect Switch
Type
--- Reel
Packaging
--- +150C
Maximum Operating Temperature
--- ±32G
Release Point Min-Max (Brp)
--- -40C
Minimum Operating Temperature
--- N/A
Maximum Output Current
--- SMD/SMT
Mounting Style
--- ±40G
Operating Point Min-Max
--- 2mA
Operating Supply Current
N/A
Response Time
N/A
Current Rating
N/A
Frequency Range
N/A
Accuracy
