مشخصات

  • Part Number
    LMC660CN
  • Series
    LMC660
  • Mounting Style
    Through Hole
  • Shutdown
    No Shutdown
  • Ib - Input Bias Current
    4pA
  • Number of Channels
    4
  • Packaging
    Tube
  • CMRR - Common Mode Rejection Ratio
    62dB
  • Minimum Operating Temperature
    0C
  • SR - Slew Rate
    1.1V/us
  • GBP - Gain Bandwidth Product
    1.4MHz
  • Maximum Operating Temperature
    70C+
  • Output Current per Channel
    40mA
  • Supply Voltage - Max
    15.5V
  • Vos - Input Offset Voltage
    6mV
  • Supply Voltage - Min
    4.75V
  • Package-Case
    MDIP-14
  • Operating Supply Current
    2.7mA
